60 Micron Ss Metal Polymer Pleated Mesh / Fiber Felt Filter Candle / Cartridge
leated Mesh / Fiber Felt Filter Candle / Cartridge
Pleat filter element also named stainless steel pleated filter element made of pleated stainless steel sintered fiber web and stainless steel weaving wire cloth.
Stainless steel sintered fiber felt made of stainless steel fiber by sintering in high temperature into a graded pore structure. It features high precision filtration which takes advantages of high porosity, high dirty capacity, high regeneration capacity, etc. It can be also used after chemical cleaning.
Stainless steel woven wire cloth is made of stainless steel wire using different woven ways. It features different filtration rate due to its different mesh opening and diameter. As the filter medium, it has the advantages of good strength, heat-resistance, smooth wire pore, easily washable, high temperature resistance, corrosion resistance, etc.
Pleated filter element is widely used in chemical fiber, petroleum, chemical industry, electric powder filtration.
leated Mesh / Fiber Felt Filter Candle / Cartridge Specifications
| Material | SS304, SS316, SS316L sintered fiber woven wire cloth |
| Filter precision | 1 - 300μm |
| Filter efficiency | ≥95% |
| Working pressur | 30Mpa |
| Working temperature | ≤600°C |
| Main filter media | stainless steel sintered fiber web and stainless steel wire woven cloth |
| Installing form | standard (using o-ring to seal), thread, tie rod, flange, fast interface
|
leated Mesh / Fiber Felt Filter Candle / Cartridge Feature
- Ideally Suited for Most LCD and TFT Wet Processing Applications and the Filtration of High Purity Water
- Wide Range of Filter Media and Removal Ratings Available Enabling Optimization of many Processes.
- Compact Cartridge Design Offers Long On-Stream Life Reducing Equipment Down-Time and Maintenance Costs
- Various Gaskets/O-Rings Materials-Compatible with Many Fluids
- High Purity Polypropylene Hardware Construction-Inert to Many Process Fluids Ensuring Wide Chemical Compatibility
- Stainless Steel Structure
leated Mesh / Fiber Felt Filter Candle / Cartridge Informations
| Product Type | Material | Micron | Out Diameter | Length | adapter | O-rings | Filter Media |
| Pleated Type | SS304 | 1,3,5, 10,15, 20,25, 30,40 ,50,100 etc | 30mm | 5" | Thread | Silicon | SS wire mesh |
| SS304L | 50mm | 10" | DOE | Buna-N | Sintered Fiber |
| SS316 | 60mm | 20" | 226 | Viton | Sintered mesh |
| SS316L | 65mm | 30" | 222 | EPDM | |
| Other | 70mm | 40" | SOE | | |
Note: 1. the above options are freely combined .
2.It also can be customized according to your requirements.
